LIVESTREAMING

• RTMP-based livestreaming of any input or output (including Multiviewer) 

• Compatible with all major Web platform such as YouTube, Facebook or Twitch.tv 

• Streaming to a private network to feed local clients like OBS software 

• Encoding at 1080p30 in H.264 for the video and AAC for the audio 

• Predefined video quality sets or custom bitrate for dedicated application 

• Management of the personal credentials for web services (URL and Private Key) 

         13 INPUTS

• 6x HDMI 2.0 - up to 4K60 8-bit 4:4:4 or 4K60 12-bit 4:2:2

• 3x DisplayPort 1.2 - up to 4K60 10-bit 4:4:4 or 4K60 12-bit 4:2:2

• 2x 12G/6G/3G-SDI (level A & B) - up to 4K60 10-bit 4:2:2

• 2x HDMI 1.4 or 3G-SDI (user selectable input plug) - up to 2K60 10-bit 4:4:4 (HDMI) or 2K60 10-bit 4:2:2 (SDI)

• Support custom input formats up to 4096 width / height

         4 ACTIVE OUTPUTS

• 2 outputs with mirrored HDMI 2.0 and 12G-SDI connectors (level A & B)

• 2 outputs with mirrored HDMI 2.0, 12G-SDI (level A & B) and SFP+ connectors (compatible with Analog Way's fiber optic or ST2110 SFP modules)

• Up to 4K60 8-bit 4:4:4 or 4K60 12-bit 4:2:2 (HDMI)

• Up to 4K60 10-bit 4:2:2 (SDI / SFP+)

• Support custom output formats up to 4096 width / height
